Схематичное отображение расположения, основных узлов топливной системы двигателя D12 с указанием каталожных номеров.

1

VG1246080050

Fuel injection pump

1

1

1

1

1

1

1

1

2

VG1246080028

O-ring

1

1

1

1

1

1

1

1

3

R61540080312

Woodruff key

1

1

1

1

1

1

1

1

4

VG1246080056

Flange

1

1

1

1

1

1

1

1

5

VG1246080027

O-ring

1

1

1

1

1

1

1

1

6

Q150B1035TF2

Hex head bolt

4

4

4

4

4

4

4

4

7

Q40110

Washer

4

4

4

4

4

4

4

4

8

VG1246080029

Fuel injection pump gear

1

1

1

1

1

1

1

1

9

VG1246130010

Hexagon nut

1

1

1

1

1

1

1

1

10

Q150B1045TF2

Hex head bolt

2

2

2

2

2

2

2

2

11

Q150B1035TF2

Hex head bolt

2

2

2

2

2

2

2

2

12

VG1246080042

Washer

4

4

4

4

4

4

4

4

13

VG1246080054

Bracket

1

1

1

1

1

1

1

1

14

Q150B1220

Hex head bolt

2

2

2

2

2

2

2

2

15

Q40112

Washer

2

2

2

2

2

2

2

2

16

Q40312

Spring washer

2

2

2

2

2

2

2

2

17

VG1246080055

Bracket

1

1

1

1

1

1

1

1

18

Q150B1250

Hex head bolt

2

2

2

2

2

2

2

2

19

VG1246080044

Washer

2

2

2

2

2

2

2

2

20

Q40312

Spring washer

2

2

2

2

2

2

2

2

21

Q150B1025

Hex head bolt

1

1

1

1

1

1

1

1

22

VG1246080042

Washer

1

1

1

1

1

1

1

1

23

Q40310

Spring washer

1

1

1

1

1

1

1

1

25

VG1540080018A

O-ring

6

6

6

6

6

6

6

6

26

VG1540080019B

Washer

6

6

6

6

6

6

6

6

27

VG1540080095

O-ring

6

6

6

6

6

6

6

6

28

VG1246080039

Fuel injector clamp

6

6

6

6

6

6

6

6

29

VG1099040030

Hex head bolt

6

6

6

6

6

6

6

6

30

VG1099040010

Nut

6

6

6

6

6

6

6

6

31

VG1540080024

Spherical washer

6

6

6

6

6

6

6

6

32

VG1099089065

Fuel return pipe

6

6

6

6

6

6

6

6

33

VG1099089064

Tie-in

12

12

12

12

12

12

12

12

34

VG1246080001

Injection pipe assembly

1

1

1

1

1

1

1

1

35

Q150B0620

Hex head bolt

4

4

4

4

4

4

4

4

36

Q41806

Spring washer

4

4

4

4

4

4

4

4

37

VG1246080066

Bracket

1

1

1

1

1

1

1

1

38

VG1246080067

Bracket

1

1

1

1

1

1

1

1

39

VG1246080068

Bracket

1

1

1

1

1

1

1

1

40

VG1246080069

Bracket

1

1

1

1

1

1

1

1

41

VG1246080070

Fuel injection pipe

1

1

1

1

1

1

1

1

42

VG1246080008

Fuel return pipe assembly

1

1

1

1

1

1

1

1

43

VG1246080077

Hollow bolt

6

6

6

6

6

6

6

6

44

VG1540080200

Sealing washer

12

12

12

12

12

12

12

12

45

190003962603

Hollow bolt

1

1

1

1

1

1

1

1

46

VG9003080002

Sealing washer

2

2

2

2

2

2

2

2

47

VG1540080070

Mounting plate

1

1

1

1

1

1

1

1

48

Q150B1020

Hex head bolt

2

2

2

2

2

2

2

2

49

Q40310

Spring washer

2

2

2

2

2

2

2

2

50

Q40110

Washer

2

2

2

2

2

2

2

2

51

VG1540080067

Fuel temp sensor bracket

1

1

1

1

1

1

1

1

52

Q150B0645

Hex head bolt

2

2

2

2

2

2

2

2

  53

Q40306

Spring washer

2

2

2

2

2

2

2

2

  54

Q40106

Washer

2

2

2

2

2

2

2

2

55

VG1540080071

Oil return bracket

1

1

1

1

1

1

1

1

56

Q150B0645

Hex head bolt

2

2

2

2

2

2

2

2

57

Q40306

Spring washer

2

2

2

2

2

2

2

2

58

Q40106

Washer

2

2

2

2

2

2

2

2

59

VG1246080079

Fuel return pipe

1

1

1

1

1

1

1

1

60

190003962603

Hollow bolt

2

2

2

2

2

2

2

2

61

VG9003080002

Sealing washer

4

4

4

4

4

4

4

4

62

VG1246080015

Common rail relief pipe

1

1

1

1

1

1

1

1

63

190003962607

Hollow bolt

1

1

1

1

1

1

1

1

64

VG9003080003

Sealing washer

1

1

1

1

1

1

1

1

65

VG1246080017

Fuel injection pump relief pipe

1

1

1

1

1

1

1

1

66

VG1246080013

Fuel filter relief pipe

1

1

1

1

1

1

1

1

67

190003962621

Hollow bolt

3

3

3

3

3

3

3

3

68

VG1540080022

Overflow valve

1

1

1

1

1

1

1

1

69

VG9003080005

Sealing washer

8

8

8

8

8

8

8

8

70

VG1246080019

Fuel pipe

1

1

1

1

1

1

1

1

71

VG1246080012

Fuel pipe

1

1

1

1

1

1

1

1

72

VG1246080011

Fuel pipe

1

1

1

1

1

1

1

1

73

VG1246080014

Hollow bolt

4

4

4

4

4

4

4

4

74

VG9003080006

Sealing washer

8

8

8

8

8

8

8

8

75

VG1246080016A

Oil pipe

1

1

1

1

1

1

1

1

76

190003962607

Hollow bolt

1

1

1

1

1

1

1

1

77

VG9003080003

Sealing washer

2

2

2

2

2

2

2

2

78

VG1246080020

Primary fuel filter bracket

1

1

1

1

1

1

1

1

79

VG1246080023

Final fuel filter bracket

1

1

1

1

1

1

1

1

80

Q1841050

Hex head bolt

6

6

6

6

6

6

6

6

-

VG1246080075

Primary fuel filter assembly

1

1

1

1

1

1

1

1

81

VG1246080088

Primary fuel filter body

1

1

1

1

1

1

1

1

-

VG1096080037

Oil filter and drain valve with sensor

1

1

1

1

1

1

1

1

82

VG1540080211

Oil filter

1

1

1

1

1

1

1

1

83

VG1096080034

Drain valve with water sensor

1

1

1

1

1

1

1

1

-

VG1246080086

Final fuel filter assembly

1

1

1

1

1

1

1

1

84

VG1246080089

Final fuel filter body

1

1

1

1

1

1

1

1

85

VG1540080110

Final fuel filter

1

1

1

1

1

1

1

1

86

Q150B1025

Hex head bolt

4

4

4

4

4

4

4

4

87

Q41810

Spring washer

4

4

4

4

4

4

4

4

88

R61540080016

Rail

1

1

1

1

1

1

1

1

88-1

095420-0260

Valve fuel

1

1

1

1

1

1

1

1

88-2

499000-6160

Sensor

1

1

1

1

1

1

1

1

89

Q150B0855

Hex head bolt

2

2

2

2

2

2

2

2

90

Q41808

Spring washer

2

2

2

2

2

2

2

2
